Description
The SA8345 is one channel H-Bridge
driver IC, it provides integrated
motor-driver solution for smart hardware, robotics, consumer products and other
12V DC powered or battery-powered
motion control applications. The SA8345 maximum operational
voltage is 25.0V. It can supply up to 3.5A
of output continuous current and 6.0A of
output peak current. There is internal
shutdown function for over-temperature
protection and over-current protection
(IOCP = 6.0 A). Package material is Pb-Free Product &
RoHS compliant for the purpose of
environmental protection and for
sustainable development of the earth.
Features
 Operation voltage up to 25.0V
 Continuous current output up to 3.5A
 Peak current up to 6.0A
 RDSON: 180-mΩ (HS + LS)
 Support PWM control
 Over current protection
 Over temperature protection
 UVLO protection
 Low standby current
 Low quiescent current
 ESOP8 package
Application
 Robotics (R/C servo, Sweeping
robot)
 Smart Hardware
 Relay Driver
 Any relevant DC motor applications
